10/100/1000M Unmanaged Poe Switch , 5 Port Gigabit Ethernet Switch MTK7530U Chipset

Brand Name : E-link China

Model Number : LNK-305

Certification : CE, RoHS, FCC

Place of Origin : Shenzhen, China

MOQ : 1 piece

Payment Terms : T/T, Western Union, MoneyGram, Paypal

Supply Ability : 1000000000pcs/Month

Delivery Time : 3-5 working days

Packaging Details : 10 piece in 1 carton box

Chipset : MTK7530U

Standards : IEEE802.3 10Base-T, IEEE802.3u 100Base-TX

Switching Capacity : 10G

MAC : 4K Automatically learning, automatically Update

Number of Ports : 5x 10/100/1000Mbps Auto-Negotiation ports

LED indicators : 10/100/1000M Link/Act, Other Power

Power : DC5V/1A

Power consumption : 1.5W

Contact Now

10/100/1000M Unmanaged Poe Switch , 5 Port Gigabit Ethernet Switch MTK7530U Chipset

10/100/1000M Unmanaged Poe Switch , 5 Port Gigabit Ethernet Switch MTK7530U Chipset

Model: LNK-305 Series

Overview

E-link LNK-305 series is 5 port 10/100/1000Mbps unmanaged switch, offer 5 port 10/100/1000Mbps auto negotiation port, high integration design, small and exquisite, portable, suit for medium and small office and home network. Using store-and-forward technology, combined with dynamic memory allocation, ensure allocate to each port effectively. Its wires peed switching that forwards packets can be as fast as the speed that your network delivers those packets to them.

Features

  • Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode
  • Non-blocking switching architecture that forwards and filters packets at full wire-speed for maximum throughput
  • Auto-MDI/MDIX eliminates the need for crossover cables
  • Supports MAC address auto-learning and auto-aging
  • Auto-negotiation ports provide smart integration between 10Mbps, 100Mbps and 1000Mbps hardware
  • Fanless design ensures quiet operation
  • Desktop or wall-mounting design
  • Plug and Play design simplifies installation

Technical Parameters

Parameter Specification
Chipset MTK7530U
Standards IEEE802.3 10Base-T, IEEE802.3u 100Base-TX
Network Media (Cable)

10Base-T: UTP category 3, 4, 5 cable (maximum100m)

100Base-Tx: UTP category 5, 5e cable (maximum 100m)

1000Base-Tx: UTP category 5, 5e cable (maximum 100m)
Switching Capacity 10G
MAC 4K Automatically learning, automatically Update
Number of Ports 5x 10/100/1000Mbps Auto-Negotiation ports
LED indicators 10/100/1000M Link/Act, Other Power
Bit error rate <1/1000000000
Transfer Method Store-and-Forward
MTBF 100000 hours
Power DC5V/1A
Power consumption 1.5W
Working temperature -10~60℃
Storage temperature -40~80℃
Humidity 5%~90% non-condensing
Dimension 22mm (H)×68mm(W)×88mm (D)

Ordering Information

Model Description
LNK-305 5x 10/100/1000M Unmanaged Ethernet Switch, DC5V/1A
